| 参数Parameter | XL50 |
|---|
| 钻孔深度/Drilling depth | 50m |
| 钻杆直径/Drill rod diameter | Φ42mm Φ50mm |
| 钻孔倾斜角/Drilling inclination angle | 左右/Left and right 3°, 前倾/Forward inclination |
| 最大扭角/Maximum torque | 1800 N.m |
| 行驶速度/Travel speed | 1.5km/h |
| 最大爬升速度/Maximum climbing gradient | 25° |
| 动力头转速/Power head rotation speed | 高/High 0-240r/min, 低/Low 0-80r/min |
| 动力头最大行程/Power head maximum stroke | 3500mm |
| 动力头额定提升力/Power head rated lifting force | 30kN |
| 动力头允许压力/Power head allowable pressure | 12kN |
| 扬程提升/加压速度/Power head lifting/pressure speed | 旋喷微调速度/Fine adjustment speed for rotary spraying 0.06-0.9/1.8m/min |
| 动力头快速提升/Power head rapid elevation | 0～22/0～28m/min |
| 主泵系统压力/Main pump system pressure | 20MPa |
| 辅助泵系统压力/Auxiliary pump system pressure | 16MPa |
| 电机功率/Motor power | 22kW |
| 外形尺寸/Overall dimensions in mm | 工作模式/(Working mode)2768×1800×4566，运输方式/(Transportation mode)4500×1800×1800 |
| 总重/Total weight | 2500kg |
