| 参数Parameter | ZML70 |
|---|---|
| 整机尺寸（长*宽*高）/Overall dimensions | 4000*1700*2300mm |
| 耗气量/Gas consumption | 9~22m³/min |
| 钻孔角度/Drilling angle | 0~360° |
| 钻孔直径/Drilling diameter | φ90~250mm |
| 钻孔规格/Drilling specifications | φ76*1500/2000/3000 |
| φ89*1500/2000/3000 | |
| 动力头输出转速/Power head output speed | 35~70rpm |
| 动力头输出扭矩/Power head output torque | 4200N.m |
| 动力头提升力/Power head lifting force | 45kN |
| 动力头给进力/Power head feeding force | 35kN |
| 钻机重量/Weight | 3800kg |
| 电机功率/Motor power | 22kw |
| 内燃机功率/Diesel engine power | 37kw |
