| 参数Parameter | ZML120 |
|---|
| ZML-120纯电动功率/ZML-120 electric motor power | 30kw |
| ZML-120柴动行走电动施工/ZML-120 diesel and electric motor power | 37kw |
| 整机/The whole machine |
| 钻机运输状态外廓尺寸(凿岩系列）/Overall dimensions | 6600*2000*2800mm |
| 液压系统额定压力/Hydraulic system rated pressure | 18 (Mpa) |
| 钻孔角度/Drilling angle | 360 ° |
| 桅杆回转角度/Mast rotation angle | 360 ° |
| 水平高度/Horizontal height | 4.5m |
| 动力头最大行程/Maximum stroke of power head | 2500 (mm) |
| 副轨道行程/Secondary track travel: 1000 (mm) | 副轨道行程/Secondary track travel: 1000 (mm) |
| 爬坡能力/Climbing ability | ≤ 25 ° |
| 接地比压/Grounding specific pressure | 0.04 (Mpa) |
| 钻机总重/The total weight | about 5000 (kg) |
| 凿岩动力头/Rock driller |
| 纤尾规格/Shank | R32/R38/T38/T45 |
| 冲击功率/Impact power | 18kw |
| 冲击频率/Impact frequency | 2900-3700 (bpm) |
| 回转速度/Rotating speed | 130-210 (rpm) |
| 回转扭力/Rotating torque | 880 (N.m) |
| 动力头最大提升力/Maximum lifting force | 20 (kn) |
| 动力头最大进给力/Maximum feed force | 20 (kn) |
| R32纤尾/R32 shank |
| 钻孔范围/Drilling range | Φ 51- Φ76 |
| Φ 45 （仅适用于单钎杆钻进）/(only applicable to single drill rod drilling) |
| 钻孔深度/Drilling depth | 10m (Max) |
| 围岩等级/Rock level | 3-6级/level |
T38纤尾/T38 shank
|
| 钻孔范围/Drilling range | Φ 64- Φ89 |
| Φ 45 （仅适用于单钎杆钻进）/(only applicable to single drill rod drilling) |
| 钻孔深度/Drilling depth | 15m (Max) |
| 围岩等级/Rock level | 3-6级/level |
| T45纤尾/T45 shank |
| 钻孔范围/Drilling range | Φ 76- Φ 102 |
| Φ 70 （仅适用于单钎杆钻进）/(only applicable to single rod drilling) |
| 钻孔深度/Drilling depth | 25m (Max) |
| 围岩等级/Rock level | 3-6级/level |
