| 参数Parameter | CYTM41A |
|---|
| 整机尺寸（长*宽*高）/Overall dimensions (L*W*H) | 10370*2060*2500mm |
| 适用断面/Applicable cross-section (b*h) | 5.2m*6.6m |
| 凿孔直径/Drill hole diameter： | φ38mm- φ43mm |
| 推进器总长/Total length of the mast | 3420mm |
| 锚杆长度/Anchor rod length: | 2000mm |
| 液压油箱容量/Hydraulic oil tank capacity | 170L |
| 整机重量/Whole machine weight | 12100kg（±300） |
| 钻臂/Drilling arm |
| 钻臂俯仰角度/Drill arm angle（downward/upward）: | 32°/55° |
| 钻臂摆动角度/Drill arm swing angle: | ± 35 ° |
| 臂身回转角度/Drill arm rotation angle: | ± 120 ° |
| 臂身水平伸缩长度/Drill arm horizontal extension length: | - 900mm |
| 抓网臂/Web grabbing arm |
| 大臂俯角度/Big arm downward angle | 25° |
| 大臂摆动角度/Big arm swing angle: | ±45° |
| 大臂回转角度/Big arm rotation angle: | ±180° |
| 大臂水平伸缩长度/Big arm horizontal telescopic length: | 1455mm |
| 小臂俯仰角度/Small arm angle（downward/upward）: | 90°/90° |
| 行走机构/Travel mechanism |
| 发动机功率/Engine power: | 60kw (2200rpm) |
| 行走速度/Travel speed: | ≤12km/h |
| 后桥摆动角/Rear axle swing angle: | 7°（±1°） |
| 爬坡能力/Climbing ability | 24% |
| 液压泵站/Hydraulic pump station |
| 电动机额定功率/Rated power of electric motor | 55kw |
| 电动机额定电压/Rated voltage of electric motor | 380v |
| 电动机额定转速/Rated speed of electric motor | 1475r/min |
| 电气系统/ Electrical system |
| 流量/Flow rate: | 0.35m ³/ Min |
| 工作气压/Operation air pressure | 0.3-0.8Mpa |
| 供水系统/ Water supply system |
| 流量/Flow rate: | 52L/min |
| 工作水压/Working water pressure: | 0.8-1.2Mpa |
