| 参数Parameter | ZM60 |
|---|
| 冲击器/Impactors | CIR系列/ series, DHD 系列/series |
| 压碎法/Crushing method | 冲击旋转/Impact rotary |
| 钻杆规格/Drill rod specifications (mm) | Φ76*1500 |
| Φ89*1500 |
| 动力头输出速度/Power head output speed (rpm) | 0-44 |
| 动力头最大扭矩/Power head maximum torque (N.m) | 3390
|
| 动力头最大行程/Power head maximum stroke (mm) | 1800 |
| 补偿冲程/Compensation stroke (mm) | 500 |
| 动力头最大提升力/Power head maximum lifting force (kN) | 50 |
| 动力头最大进给力/Power head maximum feeding force (kN) | 35 |
| 液压系统额定压力/Hydraulic system rated pressure (MPa) | 16 |
| 电机功率/Motor power (kW) | 22 |
| 钻机总重/Total weight of the drilling rig (kg) | 1500 |
| 运输状态下的钻机尺寸/Dimensions of the drilling rig in transport state | 3140×980×1340 |
| 钻机垂直状态下的尺寸/Dimensions of the drilling rig in vertical state | 2260×980×3150 |
| 液压站尺寸/Dimensions of the hydraulic station (mm) | 1420×620×1350 |
| 控制面板尺寸/Dimensions of the control panel (mm) | 720×710×920 |
