| 参数Parameter | WH10 |
|---|---|
| 整机尺寸（长*宽*高）/Overall dimensions (length * width * height) | 12500*2400*3550/2850mm |
| 作业范围（b*h）/ Operation range (b * h) | 16140*12160m |
| 最小转弯半径/Minimum turning radius | ≤10m |
| 整机重量/Overall weight | 29500 ± 50Kg |
| 钻臂/Drilling arm | |
| 数量/ Qty | 2 |
| 控制方式/ Control method | 平动定位式/ Translational positioning |
| 伸缩行程/ Expansion stroke | 4000mm |
| 升降及摆动角度/ Lift and swing angle | 升降/ Lifting and lowering (+55°, -30°) 摆动/ Swing (Left 45°, right 45°) |
| 平台回转角度/ Platform turning angle | 90° |
| 底盘/Chassis | |
| 行走速度/ Travel speed | ≤ 12 (km/h) |
| 爬坡能力/ Climbing ability | ≤ 24% |
| 离地间隙/ Ground clearance | ≥ 420mm |
| 前/后轮胎型号/ Front and rear tire type | 14-R24 |
| 发动机品牌/ Engine brand | 潍柴/ Weichai |
| 传动系统功率/ Transmission system power | 164kw |
| 废气排放标准 | 国Ⅲ |
| 四轮液力驱动/ Four-wheel hydraulic drive | 是/ Yes |
| 制动系统/ Brake system | 湿式全液压制动/ Wet full hydraulic brake |
| 转向系统/ Steering system | 铰接转向/ Shoval steering |
| 燃油箱容积/Fuel tank | 160L |
| 钻机系统控制类型/ Drill rig system control type | 远程电控 + 本地控制先导/ Remote electric control + local control pilot |
| 钻机控制系统/ Drill rig control system | |
| 控制面板类型/ Control panel type | 手柄式/ Handle |
| 电子系统供电类型/ Electronical system power supply | 24VDC |
| 钻臂控制类型/ Drilling arm control type | 电液多路阀控制/ Electro-hydraulic multiway valve control |
